Özellik
- We wholesale fiber optic pigtails at unbeatable price
- Excellent Quality
- Custom length - OK
- Custom connector type - OK
- Custom connector count - OK
- Custom package, sticker - OK
- Custom Color - OK
- Rapid delivery
Temel Özellikler
Prefabricated fiber optic connector components are designed for indoor and outdoor fiber optic access networks. This terminal provides users with protection and fast and convenient incremental cable connections, while also improving deployment speed. Its reliability and flexibility make it an ideal choice for fiber optic access networks outside of factories,including network access point terminals in fiber to home (FTTH) network deployments.
replace traditional water blocking ointment, Corning ClearCurve fiber. This is a revolutionary fiber optic cable and cable. The optical cable assembly adopts a fully dry design, using water blocking yarn and wrapped water blocking tape to that is not sensitive to bending and can ensure almost no attenuation loss even in sharp bends.
Özellik
- Cost effective solution for in house termination
- Low insertion loss and added loss
- The material in the jumpel cable are all-weather and UV-resistant
- Mechanical performance: IEC 61754-4 standard
- RoHS and REACH materials compliant
Başvuru
- Telecommunication networks
- Outdoor communication equipment connection
- Remote wireless base station
- FTTX applications
Specification
Product Name | Fiber Optic Pigtail |
Fiber Type | Single/Multi Mode, G652D/G657A1/G657A2/OM1/OM2/OM3/OM4/OM5 |
Jacket Material | LSZH/PVC/OFNP/OFRP |
Cable Diameter | 2.0mm/3.0mm/5.0mm/Customize |
Connector Type | SC/LC/FC/E2000/ST/Fast Connector/MPO/MTP |
End Face | UPC/APC/PC |
Working Wavelength (nm) | 850-1300/1310-1550 |
Insertion Loss (dB) | ≤ 0.2dB |
Return Loss (dB) | UPC ≥ 50dB |
Operating Temperature （℃) | －40~85 |
Jacket Color | Yellow/Red/Black/White/Violet/Customize |
SSS
Evet. 500'den fazla çalışanımızla gerçek üreticiyiz.
Evet, küçük siparişler mevcuttur. İşin her zaman küçük siparişlerden oluştuğunu bildiğimiz için müşterilerimizin yeni projelerini destekliyoruz.
Lan kablosu için 10 yıl, fiber optik kablo için 25 yıl
ISO9001, SGS, UL, CPR, CE, RoHs
Genellikle 10-15 iş günü içinde
Lan Kablosu, yıllık üretimimiz 500000*305m
Dış Mekan/İç Mekan Fiber Optik Kablo, yıllık üretimimiz 8.000.000 KM;
FTTH/FTTX/FTTA Kablosu, yılda 6.000.000 KM'dir;
Patch Cord/Pigtails, yılda 12.400.000 Adettir.
T/T, L/C, Western Union ve Ali ödeme yapar.
Evet. OEM ve ODM hizmeti veriyoruz. Çiziminizi bize gönderebilir veya profesyonel özelleştirilmiş ekibimiz tarafından tasarım yapabiliriz.
