Feature
- Suitable to be used in harsh environments
- Long distance coverage (continuous temperature measurements)
- Ease of installation
- Provide wide operating temperature, which ranges to as high as 300 degree Celsius with the use of the ASI fiber
- Able to customize with singlemode & multimode fiber within a single cable
Core Specifications
Kategoria | Single mode（1310nm/1550nm） | multimode （50/125μm） （850nm/1300nm） | multimode （62.5/125μm） （850nm/1300nm） | |
Attenuation | Typical | 0.36/0.22 | 3.0/1.0 | 3.0/1.0 |
| Max | 0.4/0.3 | 3.5/1.5 | 3.5/1.5 |
Zero dispersion slope | <0.093 ps/km·nm2 | / | / | |
Chromatic dispersion（1285-1340nm） | -3.5~3.5ps/（nm•km） | / | / | |
MFD（@1550） | 9.3±0.4μm | / | / | |
Cut-off wavelength | ≤1260nm | / | / | |
Bandwidth | @850nm | / | ≥500MHz•km | ≥200MHz•km |
| @1300nm | / | ≥1000MHz•km | ≥600MHz•km |
Cladding diameter（μm） | 125±1.0 | 125±1.0 | 125±1.0 | |
FAQ
Yes. We are the real manufacturer with more than 500 staff.
Yes, small order is available .We support new project of our customers as we know business is always from small order.
10 years for Lan cable , 25 years for fiber optic cable
ISO9001, SGS, UL, CPR, CE, RoHs
Usually within 10-15 working days
Lan Cable,our annual output is 500000*305m
Outdoor/Indoor Fiber Optic Cable, our annual output is 8,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.
T/T, L/C, Western Union and Ali pay.
Yes. We supply OEM&ODM service. You can send us your drawing or we make design by our professional customized team.
