GYTS Outdoor Fiber Optic Cable Steel Wire Strength Member HDPE Armoured Fiber Optic Cable GYTS/GYTA

Stranded Loose Tube Light-armored Fiber Optical Cable GYTS/GYTA

$
GYTA is an outdoor use optical fiber cable suitable for duct and aerial applications. We supply GYXTW fiber optic cable from 2 fiber cores to 288 fiber cores. Both single mode type and multimode types are available.

Feature

GYTS Outdoor Fiber Optic Cable Steel Wire Strength Member HDPE Armoured Fiber Optic Cable GYTS/GYTA

Core Specifications

Items

Descriptions

Cable type

GYTA

GYTS

Optical fiber

Counts

2-288



Color

Blue、Orange、Green、Brown、Slate、White、Red、Black、Yellow、Violet、Pink、Aqua

Loose tube

Diameter(mm)

1.6/1.8



Color

Blue、Orange、Green、Brown、Slate、White、Red、Black、Yellow、Violet、Pink、Aqua



Material

PBT



Infilling

Filling compound

Filler

Diameter(mm)

The same to the diameter of Loose tube



Material

PP

Center strength member

Material

Steel wire or PE coated steel wire

Armor layer

Plastic-coated Aluminium Strip

Plastic coated steel strip

Outer sheath

Diameter(mm)

8.8-13.5



Material

PE



Color

Black

FAQ

Yes. We are the real manufacturer with more than 500 staff.

Yes, small order is available .We support new project of our customers as we know business is always from small order.

10 years for Lan cable , 25 years for fiber optic cable

ISO9001, SGS, UL, CPR, CE, RoHs

Usually within 10-15 working days

Lan Cable,our annual output is 500000*305m
Outdoor/Indoor Fiber Optic Cable, our annual output is 8,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.

T/T, L/C, Western Union and Ali pay.

Yes. We supply OEM&ODM service. You can send us your drawing or we make design by our professional customized team.
