Network Cable

A network cable, also known as an Ethernet cable, is a type of cable used to connect devices in a computer network. It is designed to transmit data between computers, switches, routers, and other networking devices.

There are different types of network cables, but the most common are twisted pair cables, which consist of four pairs of wires that are twisted together and encased in a protective jacket. These cables come in various categories, such as Category 5 (Cat 5), Category 6 (Cat 6), and Category 7 (Cat 7), with each category having specific transmission speeds and bandwidths.

Specifications:

·CCA or 23AWG Soft Plain Copper.
·Eco-friendly,pollution-free and new materials selected.
·Insulation: Solid Foam PE
·Eco-friendly PVC Jacket /LSZH Jacket , 5.High-temperature resistance,long working life.
·Using standard twisted construction design, small crosstalk of signal transmission upload and download in high speed transfer.
·Support 10-Gigabit Ethernet netword transmission requirements

Applications:
·Computer Network Cabling Project.
·Broadband Network Communication.
·Digital ISDN Network and ATM 155Mbps Network
·Ethernet Network
·Audio and Data Transmission

Specification:

quality CAT6 UTP 4 Pair network cable

·Sample available.
·OEM services.
·Official authentication: ROHS ,CE,UL

Material Instruction

·CCA or 24AWG Soft Plain Copper.
·Eco-friendly,pollution-free and new materials selected.Promise new material only.
·Insulation: Solid HDPE;
·Eco-friendly PVC/LSZH Jacket , high-temperature resistance,long working life.

Applications:
·Computer Network Cabling Project.
·Broadband Network Communication.
·Digital ISDN Network and ATM 155Mbps Network
·Ethernet Network
·Audio and Data Transmission

Feature
·4 PAIRS TIGHTLY TWISTED
·REDUCEINTER SIGNALINTERINTERFERENCE
·AVOID TRANSMISSION LOSS

Core conductor: oxygen free copper
Features: high quality, gold-plated contact ,durable
Product  aterial: Plastic+OFC
Product color: transparent
Coat material: environment-friendly plastic
Scope of application: router ,IP camera ,network camera ,laptop ,computer.

Physical Electrical Characteristics
·DC resistance (max): 7.5Ω/100m at 20℃;
·Mutual capactitance (max): 5.6nF/100m;
·Unbalanced capacitance (max): 330pF/100m;
·Dielectric strength between conductors (min): 2.5kV/2s;
·Impedance: 1-100MHz   100±15Ω; 100-600MHz  100±22Ω;
·Phase velocity (max): 536ns/100m @100MHz;
·Differential phase delay (max): 30ns/100m;
·Operating temperature: -20~+60℃;
·Permitted bend radius: 15 times diameter of the cable.

Application
·Volp /ISDN/ Token
·100Mbps TP-PDM
·Analog and Data Video
·TR-16 Active and Passive
·155M/622M/1.2G ATM
·IEEE 802.3-T: 10Base-T; 100Base-T; 1000Base-T;10GBase-T

1、Is Ethernet same as network cable?

Ethernet is a type of networking technology used to transmit data over a network. It is often used with network cables, such as twisted pair cables, which are also commonly referred to as Ethernet cables.

So while Ethernet is not the same thing as a network cable, they are closely related and are often used together in networking. Ethernet provides the rules and protocols for how data is transmitted over a network, while network cables provide the physical connection for transmitting that data between devices.

2、How do I identify a network cable?

Network cables come in different types, but most commonly used are Ethernet cables. An Ethernet cable typically has an RJ-45 connector on both ends, which looks like a wider and thicker version of a telephone jack. The cable itself is usually flat or round and can be made of either PVC or plenum material.

Ethernet cables also come in different categories (Cat5e, Cat6, Cat7) that determine the speed and performance of the cable. These categories are usually printed on the cable jacket.

To identify a network cable, look for an RJ-45 connector on both ends, check the cable type, and look for any labeling or printing on the cable jacket that indicates its category or purpose.
