| Model Name: | WDZ-YJY | Conductor Type:: | Class 2 |
|---|---|---|---|
| Size:: | 1.5~630mm² | Nos.of Core:: | 2~5 |
| Sheath:: | LSZH (LOW SMOKE AND HELOGEN FREE) | Insulation :: | XLPE |
| Fire Performance:: | IEC 60332-1 | Temperature Rating：: | -25C Up To +90℃ |
| High Light: |
16mm2 Low Voltage Power Cable, 5core Low Voltage Power Cable |
||
▼wdz-yjy 5 core xlpe cable 16mm2 Low Smoke Halogen Free Cable
Application:
1kV for Fixed installations such as distribution networks or industrial installations.
Constraction:
Core Conductor :annealed copper (stranded core)
Popular sizes: 2~5 core x1.5~630mm²
Insulation: XLPE
Jacket: LSZH
Voltage suitable: 0.6/1kV
Fire performance: IEC 60332-1
Approval:QS in China
Advantage:
| Flame retardancy | In actual use, wires and cables are laid horizontally and vertically. For open wire laying and channel laying methods, our company’s low-smoke and halogen-free cables pass the bundle burning test for bundled applications, and for single-layed low-smoke halogen-free cables, they pass the single vertical burning test. |
| Smoke density | The smoke of burning gas is an important indicator of the burning performance of wires and cables, and it is also an important factor affecting fire rescue and self-rescue under actual fire conditions. The light transmittance of our company’s low-smoke halogen-free cables is not less than 60%. |
| Corrosive | The combustion of ordinary polyvinyl chloride cables produces a large amount of HCL gas. The products not only cause serious harm to the human body, but also severely corrode various fire-fighting and other facilities. After testing, the weighted value of pH should not be less than 4.3, and the weighted value of conductivity should not exceed 10μS/mm |
Technical parameters:
2 Core&3 Core
| Cross section of conductor(mm²) | Conductor structure | Insulation Thickness(mm) | Copper sheath thickness(mm) | Approx.cable diameter(mm) | Max resistance of conductor at 20℃ (Ω/km) |
| 2×6 | 1 | 0.7 | 1.8 | 11.6 | 3.08 |
| 2×10 | 7 | 0.7 | 1.8 | 13.8 | 1.83 |
| 2×16 | 7 | 0.7 | 1.8 | 15.7 | 1.15 |
| 2×25 | 7 | 0.9 | 1.8 | 18.9 | 0.727 |
| 2×35 | 7 | 0.9 | 1.8 | 20.9 | 0.524 |
| 2×50 | 10 | 1.0 | 1.8 | 24.6 | 0.387 |
| 2×70 | 14 | 1.1 | 1.9 | 28.2 | 0.268 |
| 2×95 | 19 | 1.1 | 2.0 | 32.4 | 0.193 |
| 2×120 | 24 | 1.2 | 2.2 | 35.8 | 0.153 |
| 2×150 | 30 | 1.4 | 2.3 | 39.6 | 0.124 |
| 2×185 | 37 | 1.6 | 2.5 | 44.0 | 0.0991 |
| 2×240 | 48 | 1.7 | 2.6 | 49.4 | 0.0754 |
| 2×300 | 61 | 1.8 | 2.8 | 54.3 | 0.0601 |
| 3×6 | 1 | 0.7 | 1.8 | 12.2 | 3.08 |
| 3×10 | 7 | 0.7 | 1.8 | 14.6 | 1.83 |
| 3×16 | 7 | 0.7 | 1.8 | 16.7 | 1.15 |
| 3×25 | 7 | 0.9 | 1.8 | 20.1 | 0.727 |
| 3×35 | 7 | 0.9 | 1.8 | 22.3 | 0.524 |
| 3×50 | 10 | 1.0 | 1.9 | 26.2 | 0.387 |
| 3×70 | 14 | 1.1 | 2.0 | 30.3 | 0.268 |
| 3×95 | 19 | 1.1 | 2.2 | 38.0 | 0.193 |
| 3×120 | 24 | 1.2 | 2.3 | 34.6 | 0.153 |
| 3×150 | 30 | 1.4 | 2.4 | 38.5 | 0.124 |
| 3×185 | 37 | 1.6 | 2.6 | 47.3 | 0.0991 |
| 3×240 | 48 | 1.7 | 2.8 | 53.1 | 0.0754 |
| 3×300 | 61 | 1.8 | 2.9 | 58.2 | 0.0601 |
