Feature
- Applications: Suitable for long-distance communication and indoor communication
- Installation Aerial-self supporting
- Operating temperature: -40 ~ + 70 °C
- Bend radius: static 10x cable diameter Dynamic 20x cable diameter
- Steel Messenger: 0.9mm*7;1.0mm*7;1.2mm*7;1.5mm*7
- Manufactured and tested to the ISO 11801, EN 50173 & ANSI/TIA-568-C standards
Core Specifications
Items | Descriptions | |||
Cable type
| GYTC8Y | GYTC8A | GYTC8S | |
Optical fiber | Counts | 4-144 | ||
| Color | Blue、Orange、Green、Brown、Slate、White、Red、Black、Yellow、Violet、Pink、Aqua
| ||
Loose tube | Diameter（mm） | 1.6/1.8 | ||
| Color | Blue、Orange、Green、Brown、Slate、White、Red、Black、Yellow、Violet、Pink、Aqua
| ||
| Material | PBT | ||
| Infilling | Filling compound | ||
Filler | Diameter（mm） | The same to the diameter of Loose tube | ||
| Material | PP | ||
Messenger member | Material | Strand steel wire | ||
Center strength member | Material | Steel wire or PE coated steel wire | ||
Armor layer | Material | No Armor | Plastic-coated Aluminium Strip | Plastic coated steel strip |
Outer sheath | Diameter（mm） | 9.0*17.0—13.5*21.5 | ||
| Material | PE | ||
| Color | Black | ||
FAQ
Yes. We are the real manufacturer with more than 500 staff.
Yes, small order is available .We support new project of our customers as we know business is always from small order.
10 years for Lan cable , 25 years for fiber optic cable
ISO9001, SGS, UL, CPR, CE, RoHs
Usually within 10-15 working days
Lan Cable,our annual output is 500000*305m
Outdoor/Indoor Fiber Optic Cable, our annual output is 8,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.
T/T, L/C, Western Union and Ali pay.
Yes. We supply OEM&ODM service. You can send us your drawing or we make design by our professional customized team.
